Service centres

Tata Steel’s extensive distribution network is one of the largest in the UK.

These downstream facilities provide processing, service, distribution and sales support for our customers across the UK and Ireland. Our broad service centre network offers decoiling and slitting services, as well as blanking, plate processing and roll forming.

50%

$Lisburn Service centre investment. One of the project’s main features is the high-spec steel roof which was constructed using 8,400m2 of Trisomet® 100mm insulated panels. The Trisomet® panels were manufactured at Tata Steel’s Shotton site in North W$

January 2014 - TATA Steel Park Wednesfield - Images of the Prolfiling Centre , Centre Offices and Automotive Service Centre

Slitting

We have a broad service centre network offering slitting services from stock and against short lead times.

Our processing capabilities are summarised below:

	Steelpark Wednesfield	Lisburn, Ireland
Gauge	0.20-8.00	0.50-2.90
Width	34.5-2020	60-1524
Length	Coil	Coil
Hot-rolled	Yes	Yes
Cold-rolled	Yes	Yes
Metallic coated (HDG, EZ. ZM)	Yes	Yes
Aluminium	Yes	-
Reversing mill plate (wide flats)	-	-

All dimensions in mm.

For information on our service centre networks click below:

Steelpark, Wednesfield

Heavy gauge, Llanwern

Lisburn, Ireland

Mainland Europe

Colorcoat Service Centre

Decoiling

We offer a broad range of decoiling services for a wide variety of end-user applications.

Our processing capabilities are summarised below:

	Steelpark, Wednesfield		Lisburn, Ireland	Heavy gauge, Llanwern
	Line 1	Line 2
Gauge	0.50-3.00	0.35-3.20	0.50-6.00	3.00-25
Width	150-1975	200-2000	610-2000	<2100
Length	150-4000	200-4000	300-8700	<17000
Hot-rolled	Yes	Yes	Yes	Yes
Cold-rolled	Yes	Yes	Yes	-
Metallic coated (HDG, EZ. ZM)	Yes	Yes	Yes	-
Aluminium	Yes	Yes	-	-
Reversing mill plate (wide flats)	-	-	-	-

All dimensions in mm.

Heavy gauge decoilers being transported at a warehouse facility in Llanwern

Oct 2014 - TATA Steel - Lllanwern Works , Magor , South Wales. Images of the Heavy Gauge Decoiler

Decoiled 25mm sheet being inspected at Service Center Maastrict, Feijen.

Blanking

We offer a broad range of blanking processing services.

Our processing capabilities are summarised below:

	Steelpark, Wednesfield					Lisburn, Ireland
	Light multistranding 1	Light multistranding 2	Press blanking	Trapezoidal blanking	Radial blanking	Multistranding
Gauge	0.50-3.00	0.35-3.20	0.40-3.00	0.35-3.00	0.40-3.00	0.50-2.90
Width	150-1975	600-2000	100-2050	200-2100	400-1440	250-1530
Length	150-4000	420-4000	100-5000	200-4000	300-5000	300-4000
Hot-rolled	Yes	Yes	Yes	Yes	Yes	Yes
Cold-rolled	Yes	Yes	Yes	Yes	Yes	Yes
Metallic coated (HDG, EZ, ZM)	Yes	Yes	Yes	Yes	Yes	Yes
Aluminium	Yes	Yes	Yes	Yes	Yes	-
Reverse mill plate (wide flats)	-	-	-	-	-	-

All dimensions in mm.

Tailor Welding

As part of our service we offer tailor welding.

Our processing capabilities are summarised below:

Steelpark, Wednesfield

Gauge	0.50-3.00
Width	<2800
Length	<3800
Hot-rolled	Yes
Cold-rolled	Yes
Metallic coated (HDG, EZ, ZM)	Yes
Aluminium	-
Reverse mill plate (wide flats)	-

All dimensions in mm.
